INTRODUCTION

GM

Uni-block system for low

and medium temperature
refrigeration AIR PURIFIER

For wall mounted installation in small
HEATING
and medium sized cold rooms
› Rapid mounting on the wall of the cold room by straddle-
mounting, which is ideal for both new installations and
refurbishment projects
› Metallic grey coloured finish of the outdoor unit
› The white colour of the evaporator blends unobtrusively with the SPLIT
cold room walls
› Compressor compartment insulated with suitable soundproofing
material to reduce sound levels GM
› Microchannel condensers available in order to reduce the
refrigerant charge as much as possible and ensuring higher
energy efficiency SKY AIR
› The units are provided with a new generation control panel with
an easy-to-use interface
Installation type

100/
120 VRV
500

L
L M
Agujero 83
F
Ø 28 N VENTILATION & BID- DLE AIR CURTAINS
Loch J
G
19 N
H
Through- wall model Straddle model
Low temperature refrigeration GM BGM110 BGM0870 BGM112 BGM117 BGM218 BGM220 BGM330
DA11XA Y1AA DA11XA DA11XA DA11XA DB11XA DB11XA MARINE TYPES
Refrigerating capacity Low temperature R-290 Nom kW - 0.87 (1) -
R-452A Nom kW 0.679 (1) - 0.889 (1) 1.080 (1) 1.336 (1) 1.688 (1) 2.349 (1)
Dimensions Unit HeightxWidthxDepth mm 735x400x790 830x620x790 830x620x862
Packed unit HeightxWidthxDepth mm 942x450x850 1,050x670x850 1,050x670x940
Weight Unit kg 56 64 80 105
Packed unit kg 67 75 96 122
Compressor Type Hermetic Reciprocating CHILLERS
Nominal power kW 0.74 0.9 1.3 1.5 2.2
Starting method Direct
Condenser Air flow m³/h 600 720 600 1,200 1,500
Defrost Hot gas
Evaporator Air flow m³/h 600 672 600 1,200 1,500
Air throw m 4 10
Operation range Cold room temperature Min. ~Max. °C -25~-15
Refrigerant Type/GWP R-452A/2,141 R-290/3 R-452A/2,141 FAN COIL UNITS
Charge kg/TCO Eq 0.38/0.81 0.15/0.0000 0.34/0.73 0.35/0.75 0.86/1.84 0.84/1.80 0.98/2.10
2
Power supply Phase/Frequency/Voltage Hz/V 1~/50/230 3N~/50/400
MGM103 MGM105 MGM106 MGM128 MGM107 MGM110 MGM211 MGM221 MGM212 MGM213 MGM315 MGM320
Medium temperature refrigeration GM
EA11XA EA11XA EA11XA 0Y1AA EA11XA EA11XA EA11XA 0Y1AA EB11XA EB11XA EB11XA EB11XA
Refrigerating capacity Medium temperature R-134a Nom kW 0.855 (2) 0.978 (2) 1.120 (2) - 1.315 (2) 1.351 (2) 1.806 (2) - 2.034 (2) 2.175 (2) 3.079 (2) 3.351 (2)
R-290 Nom kW - 1.31 (2) - 2.18 (2) -
Dimensions Unit HeightxWidthxDepth mm 735x400x790 830x620x790 830x620x682 AIR HANDLING UNITS
Packed unit HeightxWidthxDepth mm 942x450x850 1,050x670x850 1,050x670x940
Weight Unit kg 52 53 56 64 80 98 100
Packed unit kg 63 64 67 75 96 115
Compressor Type Hermetic Reciprocating
Starting method Direct
Condenser Air flow m³/h 600 1,200 - 1,200 1,500
Defrost Hot gas REFRIGERATION
Evaporator Air flow m³/h 600 1,200 1,125 1,200 1,800
Air throw m 4 10
Operation range Cold room temperature Min. ~Max. °C -5~10
Refrigerant Type/GWP R-134a/1,430 R-290/3 R-134a/1,430 R-290/3 R-134a/1,430
Charge kg/TCO Eq 0.40/0.57 0.43/0.61 0.15/0.00 0.33/0.47 0.40/0.57 0.71/1.02 0.15/0.00 0.70/1.00 0.75/1.07 0.95/1.36 1.00/1.43
2
Power supply Phase/Frequency/Voltage Hz/V 1~/50/230 3N~/50/400
(1) When normally running: -20°C / +30°C (2) When normally running: 0°C / +30°C CONTROL SYSTEMS
