RIO H

Ice cream freezer - horizontal:

with flat glass sliding lids

More volume, more sales. A range of
freezers to meet all circumstances

› Excellent product visibility due to low cabinet height
› Ready to plug in
› Easy-to-move, 2-part, flat glass sliding lids with the proven and
patented injected, one-piece AHT lid frame
› Environmentally friendly with natural refrigerant
› 100 % CFC and PFC free
› Low energy consumption
› Adjustable thermostat
› Intelligent fan motor for more energy efficiency – saves
approximately 0,5 kWh daily
› Reinforced insulation (72 mm) for reserve refrigeration and low
energy consumption
› Inner container made of white, pre-painted, galvanised sheet
metal
› Outer-skin condenser – no dirt, no maintenance
› Modular system: same height and depth, different lengths
available
› Suitable for climate class 3 to climate class 7
› Supplied in robust packaging (undersliding)
› Freezing: –14 °C to –23 °C

RIO H 68_EU_403766 100_EU_403767 125_EU_403768 150_EU_403769
Classification acc. EN 23953-2 7
Climate class acc. EN 23953-2 L1
Energy efficiency index EEI % 41.2 33.9 41.0 44.4
Use Display & Sale
Dimensions Gross content l 147 262 352 422
Net content l 117 215 291 367
Total display area (TDA) m² 0.29 0.46 0.59 0.73
Length Outside mm 680 1,000 1,250 1,500
Inside mm 530 850 1,100 1,350
Depth Outside mm 650
Inside mm 500
Height Outside mm 880
Stacking height mm 610
Net weight kg 51 63 71 79
Gross weight kg 55 67 76 84
Operation range Ambient Min. °C 16
temperature Max. °C 35
Relative humidity % 75 150
Product temperature Min. °C -23
Max. °C -14
Sound pressure in 1m distance dB(A) 39 40
Blowing agent R-601 (HC) GWP 5
Daily energy consumption Edaily kWh/day 2.0 / 3.0 / 1.4 2.5 / 3.8 / 1.6 2.8 / 4.0 / 1.8 3.7 / 4.8 / 2.2
Annual energy consumption AE kWh/a 474.50 511.00 730.00 912.50
HVAC Rejected heat capacity W 54 58 83 104
Dehumidification Liter/day 0
Refrigerant Type R290 / R4014A / R600a
GWP 5
Charge g 50 / 100 / 50 60 / 120 / 60 70 / 140 / 70 75 / 150 /75
Max. allowable operating pressure bar 30
Power supply Voltage V 220-240
Frequency Hz 50
Nominal power acc. EN 60335-2-89 W 240 / 230 / 120 280 / 250 / 140 300 / 350 / 160
Nominal power during defrost W 240 280 300
Nominal current during defrost A 2.1 / 1.6 / 0.7 2.3 / 1.7 / 0.9 2.5 / 2.4 / 1.1
Nominal power LED W no light
Fuse protection A 16
Defrost heater power W 220-240
Cord length mm 1750
