INTRODUCTION

PARIS

Integral freezer and

chiller cabinets
AIR PURIFIER

The chiller and freezer unit that
maximizes your product display

› High energy-saving can be achieved in comparison to HEATING
conventional open units
› Environmentally friendly with natural refrigerant propane (GWP 3)
› Brilliant LED lighting system to enhance product display & help
drive sales
› Intelligent fan motor providing more further energy savings,
typically 0.5 kWh daily SPLIT
› Plug in models, requiring no additional installation
› Virtually maintenance-free refrigeration system
› Easy clean and hygienic food safe synthetic interior casings
Flexible location options for Paris
SKY AIR
Can be used as a stand alone unit

Can be used in a line up
Can be used as an island
VRV
Maximizes the use of floor space with an end cabinet

Can be either installed below shelving or integrated into existing shelving systems
EU and UK models have same specs but different electricity plugs.

PARIS 145_EU_403751 145_UK_403775 185_UK_403776 185_EU_403752 210_EU_403753 210_UK_403777 250_UK_403778 250_EU_403754 VENTILATION & BID- DLE AIR CURTAINS
Classification acc. EN 23953-2 L1
Climate class acc. EN 23953-2 3
Energy efficiency index EEI % 39.1 38.0 34.6 32.5
Use Display & Sale
Dimensions Gross content l 609 807 936 1,136
Net content l 420 568 660 808
Total display area (TDA) m² 0.83 1.03 1.27 1.54 MARINE TYPES
Length Outside mm 1,457 1,854 2,102 2,502
Inside mm 1,328 1,723 1,973 2,373
Depth Outside mm 853
Inside mm 723
Height Outside front mm 770
Outside rear mm 833
Inside front mm 655
Inside rear mm 705 CHILLERS
Stacking height front mm 550
rear mm 550
Net weight kg 95 120 136 155
Gross weight kg 101 130 147 166
Operation range Ambient Min. °C 16
temperature Max. °C 25
Relative humidity % 60 or less FAN COIL UNITS
Product temperature Min. °C -23
Max. °C -18
Sound pressure in 1m distance dB(A) 43.6
Blowing agent R-601 (HC) GWP 5
Daily energy consumption Edaily kWh/day 5.40 6.10 6.50 7.10
Annual energy consumption AE kWh/a 1,971.00 2,226.50 2,372.50 2,591.50
HVAC Rejected heat capacity W 225 254 271 296
Dehumidification Liter/day 0 AIR HANDLING UNITS
Refrigerant Type R-290
GWP 3
Charge g 80 90 100 110
Max. allowable operating pressure bar 30
Power supply Voltage V 220-240
Frequency Hz 50
Nominal power acc. EN 60335-2-89 W 460
Nominal power during defrost W 900 REFRIGERATION
Nominal current during defrost A 3.9
Nominal power LED W 28 29 39 46
Fuse protection RCBO, 30mA, C16
Defrost heater power W 0
Cord length mm 2,400
With process-related interior fitting | Energy test results are declared for climate class 3, test procedure according to EN 23953-2 (initial door openings, 12h LED switched on with door openings, one defrost per day)
Chiller cabinets only on request CONTROL SYSTEMS
