Page 657 - General Catalogue

INTRODUCTION

MALTA

Integral freezer and

chiller cabinets
AIR PURIFIER

Create a greater impact for your customers,
as they benefit from all round product
visibility enhanced with LED lighting
HEATING
› 100 % CFC and PFC free
› Ready to plug in
› Guaranteeing the quality of the frozen goods thanks to constant
internal temperature and high power reserves
› Intelligent fan motor for more energy efficiency – saves
approximately 0,5 kWh daily SPLIT
› Brilliant LED lighting system
› Higher energy-saving
› Improved display area with optimum useful load
› Easy access from both sides
› Low investment and operating costs
› Maintenance-free SKY AIR
› Environmentally friendly with natural refrigerant propane

VRV

EU and UK models have same specs but different electricity plugs. EU and UK models have same specs but different electricity plugs.

MACAO 100_EU_403755 100_UK_403779 145_EU_403756 145_UK_403780 210_EU_403757 210_UK_403781 MALTA 145_EU_403758 145_UK_403782 185_EU_403759 185_UK_403783 VENTILATION & BID- DLE AIR CURTAINS
Classification acc. EN 23953-2 L1 Classification acc. EN 23953-2 L1
Climate class acc. EN 23953-2 3 Climate class acc. EN 23953-2 3
Energy efficiency index EEI % 54.3 46.9 40.7 Energy efficiency index EEI % 52.9
Use Display & Sale Use Display & Sale
Dimensions Gross content l 338 500 763 Dimensions Gross content l 603 795
Net content l 156 241 362 Net content l 425 571
Total display area (TDA) m² 0.49 0.76 1.13 Total display area (TDA) m² 0.73 0.99 MARINE TYPES
Length Outside mm 999 1,455 2,100 Length Outside mm 1,456 1,851
Inside mm 872 1,328 1,973 Inside mm 1,328 1,723
Depth Outside mm 850 Depth Outside mm 855
Inside mm 723 Inside mm 723
Height Outside front mm 900 Height Outside front mm 770
Outside rear mm 925 Outside rear mm 833
Inside front mm 523 Inside front mm 655
Inside rear mm 523 Inside rear mm 655 CHILLERS
Stacking height front mm 280 Stacking height front mm 550
rear mm 280 rear mm 550
Net weight kg 103 122 167 Net weight kg 103
Gross weight kg 126 130 175 Gross weight kg 110
Operation range Ambient Min. °C 16 Operation range Ambient Min. °C 16
temperature Max. °C 25 temperature Max. °C 25
Relative humidity % 60 or less Relative humidity % 60 or less FAN COIL UNITS
Product temperature Min. °C -23 Product temperature Min. °C -23
Max. °C -18 Max. °C -18
Sound pressure in 1m distance dB(A) 43.6 Sound pressure in 1m distance dB(A) 43.6
Blowing agent R-601 (HC) GWP 5 Blowing agent R-601 (HC) GWP 5
Daily energy consumption Edaily kWh/day 5.40 6.10 7.00 Daily energy consumption Edaily kWh/day 6.70 7.30
Annual energy consumption AE kWh/a 1,971.00 2,226.50 2,555.00 Annual energy consumption AE kWh/a 2,445.50 2,664.50
HVAC Rejected heat capacity W 225 254 292 HVAC Rejected heat capacity W 279 304
Dehumidification Liter/day 0 Dehumidification Liter/day 0 AIR HANDLING UNITS
Refrigerant Type R-290 Refrigerant Type R-290
GWP 3 GWP 3
Charge g 70 100 110 Charge g 80 90
Max. allowable operating pressure bar 30 Max. allowable operating pressure bar 30 30
Power supply Voltage V 220-240 Power supply Voltage V 220-240
Frequency Hz 50 Frequency Hz 50
Nominal power acc. EN 60335-2-89 W 400 Nominal power acc. EN 60335-2-89 W 460
Nominal power during defrost W 900 Nominal power during defrost W 900 REFRIGERATION
Nominal current during defrost A 3.9 Nominal current during defrost A 3.9
Nominal power LED W 17 25 34 Nominal power LED W 20 25
Fuse protection RCBO, 30mA, C16 Fuse protection RCBO, 30mA, C16
Defrost heater power W 0 Defrost heater power W 0
Cord length mm 2,400 Cord length mm 2,400
(1) - Energy test results are declared for climate class 3, test procedure according to EN 23953-2 (initial door openings, 12h LED switched on with door openings, one defrost per day) (1) - Energy test results are declared for climate class 3, test procedure according to EN 23953-2 (initial door openings, 12h LED switched on with door openings, one defrost per day)
(2) - With process-related interior fitting (2) - With process-related interior fitting CONTROL SYSTEMS
655
