EWYQ-BVP

Air cooled mini inverter

heat pump

› Top product in terms of energy efficiency and operation range
› All capacities available in 2 versions: standard version and version
with OP10 option (no freeze up of water when not in operation
thanks to the water piping heater tape)
› Easy ‚plug and play‘ installation
› Amongst the most quiet units in the market (63dBA - sound
power)
› Single phase power supply and low starting currents make the
unit ideal for residential applications
› Weight reduced with 20% compared with the previous models.
› Built-in Hydraulic kit: no buffer tank required, standard inverter
driven pump, main flow sensor and switch included.
› Standard wired remote control enables setting of different set
points (cooling, heating, water leaving temperature) or based on EWYQ-BVP EKRUMCL1
outdoor conditions (weather dependent control). It has an alarm
history, night time noise reduction function and is language
based.

Heating & Cooling EWYQ-BVP 004 005 006 008
Cooling capacity Nom. kW 4.00 / 4.01 4.93 / 5.07 5.88 / 6.07 7.95 / 8.23
Heating capacity Nom. kW 4.11 / 3.96 4.99 / 4.99 6.14 / 6.12 8.08 / 8.44
Max. kW 5.1 6.0 -
Power input Cooling Nom. kW 1.27 / 0.840 1.61 / 1.12 1.87 / 1.13 2.57 / 1.65
Heating Nom. kW 1.19 / 0.860 1.46 / 1.09 1.75 / 1.28 2.31 / 1.84
Capacity control Method Variable (inverter)
EER 3.14 / 4.80 3.06 / 4.51 3.15 / 5.35 3.10 / 4.99
COP 3.44 / 4.61 3.41 / 4.58 3.51 / 4.77 3.49 / 4.59
ESEER 4.45 4.49 5.25 5.24
Space heating Average General ηs (Seasonal % 155 159 158 165
climate space heating
water efficiency)
outlet SCOP 3.90 4.03 4.21
35°C Seasonal space A++
heating eff. class
Dimensions Unit HeightxWidthxDepth mm 735x1,090x350 997x1,160x380
Weight Unit kg 83 106
Water heat Type Brazed plate
exchanger Water Cooling Nom. l/min 11.5 / 11.5 14.1 / 14.5 16.9 / 17.4 22.8 / 23.6
flow rate Heating Nom. l/min 11.8 / 11.4 14.3 / 14.3 17.6 / 17.5 23.2 / 24.2
Water volume l 1 2
Air heat exchanger Type Cross fin coil/Hi-X tubes and chromate coated Cross fin coil/Hi-X tubes and PE coated waffle
waffle louvre fins louvre fins
Compressor Type Hermetically sealed swing compressor
Quantity 1
Fan Type Propeller fan
Quantity 1
Air flow Cooling Nom. m³/min 53 72
rate Heating Nom. m³/min 47.0 46.6 49.3
Sound power level Cooling Nom. dBA 63.0 64.0 69.0
Heating Nom. dBA 65.0
Sound pressure Cooling Nom. dBA 48.0 49.0 52.0 53.0
level Heating Nom. dBA 49.0 47.0
Operation range Air side Cooling Min.~Max. °CDB 10~43 10~46
Heating Min.~Max. °CDB -20~25 -15~25
Water side Cooling Min.~Max. °CDB 5~22
Heating Min.~Max. °CDB 15 ~55
Refrigerant Type/GWP R-410A/2,088 R-410A/2,087.5
Control Electronic expansion valve
Circuits Quantity 1
Refrigerant charge Per circuit kg 2.10 2.70
Per circuit TCO2Eq 4.4 5.6
Water circuit Piping connections diameter inch 1" MBSP
Unit Starting current Max A 15.7 19.9
Running current Max A 15.7 19.9
Power supply Phase/Frequency/Voltage Hz/V 1N~/50/230
