EWAT-B-XR

Air cooled scroll chiller,

high efficiency, AIR PURIFIER
reduced sound

HEATING

Single V

SPLIT

EWAT-B-XS/XL/XR Modular V Microtech III

SKY AIR

VRV

VENTILATION & BID- DLE AIR CURTAINS

Cooling Only EWAT-B-XR 085 115 145 180 185 200 220 230 250 280 300 310 320 360 370 430 470 540 600 660 700
Space cooling A Condition 35°C Pdc kW 81.68 108.36 135.38 167.75 165.77 187.07 207.97 223.94 238.24 264.17 284.03 283.97 301.05 327.53 345.32 393.29 437.99 500 569.48 618.9 656.69
ηs,c % 213.28 166.6 160.2 163.8 160.2 166.6 165 171.4 176.6 180.6 174.6 166.6 175 169.8 175.8 167.4 178.6 181.4 181 180.2
SEER 3.84 4.24 4.08 4.17 4.08 4.24 4.2 4.36 4.49 4.59 4.44 4.24 4.45 4.32 4.47 4.26 4.54 4.61 4.6 4.58
Cooling capacity Nom. kW 81.68 108.36 135.38 167.75 165.77 187.07 207.97 223.94 238.24 264.17 284.03 283.97 301.05 327.53 345.32 393.29 437.99 500 569.48 618.9 656.69
Power input Cooling Nom. kW 30.9 39 47 59.1 70.5 69.8 80.7 79.2 86.4 92.2 104 103 114 121 130 146 163 188 207 224 242 MARINE TYPES
Capacity control Method Staged Var. Staged Variable Staged Variable
Minimum capacity % 50 38 50 25 38 21 19 50 17 16 24 14 22 33 19 17 25 14 12 11 17
EER 2.64 2.78 2.88 2.84 2.35 2.68 2.58 2.83 2.76 2.87 2.71 2.76 2.63 2.7 2.66 2.68 2.66 2.74 2.76 2.71
ESEER 4.02 4.18 4.08 4.24 4.04 4.21 4.17 4.16 4.15 4.34 4.31 4.12 4.04 4.24 4.15 4.12 4.2 4.21 4.25 4.23
IPLV 4.74 5.1 4.76 5 4.78 5 5.05 4.82 4.93 5.09 5.15 5.02 4.72 5.05 4.9 4.86 4.82 4.91 5.07 4.99
Dimensions Unit Height mm 1,801 1,822 2,540 1,822 2,540
Width mm 1,204 2,236 1,204 2,236 CHILLERS
Depth mm 2,660 3,180 3,780 2,326 3,780 2,326 3,226 4,126 5,025 5,874 6,774
Weight Unit kg 744 837 961 1,732 1,072 1,763 1,790 1,977 2,054 2,192 2,212 2,220 2,247 2,590 2,627 2,811 3,237 3,458 3,873 4,248 4,396
Operation weight kg 752 846 968 1,743 1,088 1,773 1,801 1,997 2,066 2,209 2,234 2,241 2,277 2,614 2,655 2,848 3,268 3,497 3,916 4,290 4,432
Water heat Type Brazed plate
exchanger Water volume l 5 6 9 11 12 11 16 14 19 20 19 20 28 42 50
Water flow rate Cooling Nom. l/s 3.9 5.2 6.5 8 7.9 9 10 10.7 11.4 12.6 13.6 14.4 15.7 16.5 18.8 21 23.9 27.3 29.6 31.5
Water pressure Cooling Nom. kPa 27.8 34.2 28 36.3 38 44.2 37.7 44 48.2 35.6 55.1 40.6 45.1 71.4 57.9 49.5 60.2 52.5 66.5 62.6 69.7 FAN COIL UNITS
drop
Air heat exchanger Type Microchannel
Compressor Type Scroll
Quantity 2 4 2 4 2 4 3 4 3 4 5 6
Fan Type Direct propeller
Quantity 6 8 10 4 10 4 5 6 7 8 9 10 12 13 14
Air flow rate Nom. l/s 6,673 8,896 11,122 15,054 11,122 15,054 18,819 18,818 22,582 26,346 30,110 33,874 37,637 45,164 48,928 52,692 AIR HANDLING UNITS
Speed rpm 1,108 700 1,108 700
Sound power level Cooling Nom. dBA 77.9 81.9 84 84.2 86 84.5 84.8 86.2 85.8 86.6 87 86.7 86.9 87.7 87.6 88.3 88.9 89.3 90 90.4 90.7
Sound pressure level Cooling Nom. dBA 60.2 63.9 65.6 65.3 67.7 65.5 65.8 66.7 66.3 67.1 67.5 67.2 67.4 67.8 67.7 68.3 68.5 68.9 69.2 69.3 69.6
Operation range Air side Cooling Min.~Max. °CDB -10~46 -18~46 -10~46 -18~46
Water side Cooling Min.~Max. °CDB -13~20
Refrigerant Type/GWP R-32/675
Charge kg 10.5 12.5 15 30 16 36 37 30 42 48 36 50 52 50 58 62 70 78 80 92 100 REFRIGERATION
Circuits Quantity 1 2 1 2 1 2 1 2 1 2
Piping connections Evaporator water inlet/outlet (OD) 76.1 88.9 76.1 88.9 76.1 88.9 76.1 88.9 76.1 88.9 114.3
Unit Starting current Max A 215 315 328 290 464 388 399 505 415 543 554 555 566 591 603 639 676 725 777 814 851
Running Cooling Nom. A 60 71 83 113 118 128 143 134 151 164 177 179 194 204 221 250 276 319 352 381 410
current Max A 75 87 100 149 134 160 172 175 187 212 223 224 235 260 272 309 345 394 447 483 520
Power supply Phase/Frequency/Voltage Hz/V 3~/50/400
