INTRODUCTION

Stage 1 heat recovery between
indoor units

AIR PURIFIER

Hot water
Cooling
Heating
HEATING
heating
free hot water and
Extracted heat delivers
+
Domestic hot 45°C - 75°C VRV indoor units
water Daikin
solar
Air handling 25°C - 75°C panel
unit BS-Box
Domestic hot SPLIT
Low temp. 45°C - 75°C water tank
radiator
Underfloor BS-Box
heating 25°C - 35°C RWEYQ-T9
Heating only
hydrobox for VRV
Cooling tower (Closed type), boiler SKY AIR
or Heat rejected to loop
Low temp. 25°C - 45°C
radiator
Heat absorbed from loop
Underfloor outdoor units recovery between Stage 2 heat
heating 25°C - 35°C
Heat rejected to loop VRV
Reversible low
Liquid pipe temperature
hydrobox
Gas pipe Heat absorbed from loop
Discharge gas pipe
Hot water
* Above system configuration are for illustration purpose only.
Outdoor unit System RWEYQ 16T9 18T9 20T9 22T9 24T9 26T9 28T9
System Outdoor unit module 1 RWEYQ8T RWEYQ10T RWEYQ12T RWEYQ14T VENTILATION & BID- DLE AIR CURTAINS
Outdoor unit module 2 RWEYQ8T RWEYQ10T RWEYQ12T RWEYQ14T
Capacity range HP 16 18 20 22 24 26 28
Cooling capacity Prated,c kW 44.8 50.4 56.0 61.5 67.0 73.5 80.0
Heating capacity Prated,h kW 50.0 56.5 62.5 69.0 75.0 82.5 90.0
Max. 6°CWB kW 50.0 56.5 62.5 69.0 75.0 82.5 90.0
ηs,c % 307.6 308.7 298.1 311.3 342.6 322.5 306.1
ηs,h % 459.2 491.1 466.8 447.9 434.5 406.9 387.9
SEER 7.9 7.7 8.0 8.8 8.3 7.9 MARINE TYPES
SCOP 11.7 12.5 11.9 11.4 11.1 10.4 9.9
Recommended combination 4 x FXMQ63P7VEB 6 x FXMQ50P7VEB 4 x FXMQ50P7VEB 8 x FXMQ63P7VEB 12 x FXMQ50P7VEB 7 x FXMQ50P7VEB 2 x FXMQ50P7VEB
+ 2 x FXMQ80P7VEB + 4 x FXMQ63P7VEB + 4 x FXMQ63P7VEB + 5 x FXMQ63P7VEB + 10 x FXMQ63P7VEB
Maximum number of connectable indoor units 64 (1)
Indoor index Min. 200.0 225.0 250.0 275.0 300.0 325.0 350.0
connection Nom. -
Max. 600.0 675.0 750.0 825.0 900.0 975.0 1,050.0
Piping connections Liquid OD mm 127 159 191 CHILLERS
Gas OD mm 28.6 (2) 34.9 (2)
HP/LP gas OD mm 22.2 (3) / 28.6 (4) 28.6 (3) / 28.6 (4) 28.6 (3) / 28.6 (4) 28.6 (3) / 34.9 (4)
Total piping length System Actual m 500
Power supply Phase/Frequency/Voltage Hz/V 3N~/50/380-415
Current - 50Hz Maximum fuse amps (MFA) A 32 35 40 50
Outdoor unit System RWEYQ 30T9 32T9 34T9 36T9 38T9 40T9 42T9
System Outdoor unit module 1 RWEYQ10T RWEYQ12T RWEYQ14T
Outdoor unit module 2 RWEYQ10T RWEYQ12T RWEYQ14T FAN COIL UNITS
Outdoor unit module 3 RWEYQ10T RWEYQ12T RWEYQ14T
Capacity range HP 30 32 34 36 38 40 42
Cooling capacity Prated,c kW 84.0 89.5 95.0 100.5 107.0 113.5 120.0
Heating capacity Prated,h kW 94.5 100.5 106.5 112.5 120.0 127.5 135.0
Max. 6°CWB kW 94.5 100.5 106.5 112.5 120.0 127.5 135.0
Recommended combination 12 x FXMQ63P7VEB 6 x FXMQ50P7VEB 12 x FXMQ50P7VEB 18 x FXMQ50P7VEB 13 x FXMQ50P7VEB 8 x FXMQ50P7VEB 3 x FXMQ50P7VEB
+ 8 x FXMQ63P7VEB + 4 x FXMQ63P7VEB + 5 x FXMQ63P7VEB + 10 x FXMQ63P7VEB 15 x FXMQ63P7VEB
ηs,c % 308.3 318.2 342.5 352.3 338.8 341.4 332.9 AIR HANDLING UNITS
ηs,h % 467.2 456.1 447.0 438.5 419.4 404.4 391.2
SEER 7.9 8.2 8.8 9.0 8.7 8.5
SCOP 11.9 11.6 11.4 11.2 10.7 10.3 10.0
Maximum number of connectable indoor units 64 (1)
Indoor index Min. 375.0 400.0 425.0 450.0 475.0 500.0 525.0
connection Nom. -
Max. 1,125.0 1,200.0 1,275.0 1,350.0 1,425.0 1,500.0 1,575.0
Piping connections Liquid OD mm 19.1 (2) REFRIGERATION
Gas OD mm 34.9 41.3
HP/LP gas OD mm 28.6 (3) / 34.9 (4) 41.3 (3) / 34.9 (4)
Total piping length System Actual m 500
Power supply Phase/Frequency/Voltage Hz/V 3N~/50/380-415
Current - 50Hz Maximum fuse amps (MFA) A 50 63 80
(1) Actual number of connectable indoor units depends on the indoor unit type (VRV indoor, Hydrobox, RA indoor, etc.) and the connection ratio restriction for the system (50% <= CR <= 130%) | (2) In case of
heat pump system, gas pipe is not used (3) In case of heat recovery system (4) In case of heat pump system CONTROL SYSTEMS
