Подробные технические чертежи
CYVS_DK_FBN/FSN / CYVM_DK_FBN/FSN / CYVL_DK_FBN/FSN

CYVS_DK_FBN/FSN 500
CYVM_DK_FBN/FSN 250 250
CYVL_DK_FBN/FSN 40
O9.2
B
A
100 197

Suction grid

with filter
D
98
27
H

L

Type L H D U A B
CYVS-DK-FBN/FSN 1,000 - 1,500 270 590 93 171 119 U
CYVM-DK-FBN/FSN 2,000 - 2,500
CYVL-DK-FBN/FSN 1,000 - 1,500 370 774 124.5 245.5 200
2,000 - 2,500
CU0954X-000
REMARKS

1 The 2,500mm large devices have 3 suspension brackets, where the third bracket is mounted at half the length of the device.

CYVS_DK_CBN/CSN / CYVM_DK_CBN/CSN / CYVL_DK_CBN/CSN

CYVS_DK_CBN/CSN
CYVM_DK_CBN/CSN
CYVL_DK_CBN/CSN 500
250 250
40
O9.2
B
A
100 197
The finishing profiles are

supplied separately.
Suction grid
with filter

Screw-eye M6
98
27
H
L
Number of suction grids per device
Device length Number Suction grid length D
1000 / 1500 1 1,000 / 1,500 G
2000 / 2500 2 1,000 / 1,250
*1 drain grid per device
Type L H D U A B E F G D F
CYVS-DK-CBN/CSN 1,000 - 1,500
CYVM-DK-CBN/CSN 2,000 - 2,500 270 821 93 171 119 250 411 260 E U
CYVL-DK-CBN/CSN 1,000 - 1,500 370 1,105 124.5 245.5 200 181.5 563.5 360
2,000 - 2,500
CU0955X-000
L
REMARKS
1 The 2,500mm large devices have 3 suspension brackets, where the third bracket is mounted at half the length of the device.
2 The mounting holes for finishing profiles in a lowered ceiling (L+8) x (D+8) mm
