INTRODUCTION

EHVH-CB + ERHQ-BV3/ERHQ-BW1(7) -
Daikin Altherma R F
Daikin Altherma low

temperature split integrated AIR PURIFIER
floor standing unit

Floor standing air to water heat pump for heating
and hot water, ideal for low energy houses
HEATING
› Integrated indoor unit: all-in-one floor standing unit including
the domestic hot water tank EHVH-C
› Perfect fit for new built as well as for low energy houses
› Best seasonal efficiencies, providing the highest savings
on running costs
› Flexible configuration with respect to heat emitters SPLIT
› Outdoor unit extracts heat from the outdoor air, even at -20°C A +++
› Daikin Residential controller (optional) ERHQ011-016BW1
› Possible to connect to photovoltaïc solar panels to provide A ++ A +
energy for your heat pump (optional) up to
A + A 55°C
A B SKY AIR

Efficiency data EHVH + ERHQ-B 11S26CB9W / 16S26CB9W / 16S26CB9W / 11S26CB9W / 16S26CB9W / 16S18CB3V /
C
11S18CB3V + 16S18CB3V + B 16S18CB3V + 11S18CB3V + 16S18CB3V + 16S26CB9W +
011BV3 014BV3 016BV3 011BW1 014BW17 016BW1
Heating capacity Nom. kW 11.2(1)/ 10.3(2) 14.0(1)/ 13.1(2) 16.0(1)/ 15.2(2) 11.3(1)/ 11.0(2) 14.5(1)/ 13.6(2) 16.1(1)/ 15.1(2)
D
Power input Heating Nom. kW 2.55(1)/ 3.17(2) 3.26(1)/ 4.04(2) C 3.92(1)/ 4.75(2) 2.63(1)/ 3.24(2) 3.42(1)/ 4.21(2) 3.82(1)/ 4.69(2)
COP 4.39(1)/ 3.25(2) 4.29(1)/ 3.24(2) 4.08(1)/ 3.20(2) 4.30(1)/ 3.39(2) 4.24(1)/ 3.22(2) 4.20(1)/ 3.22(2) VRV
Space heating Average General SCOP 2.86 2.82 D 2.92 E 2.86 2.96
2.90
climate ŋs (Seasonal space % 112 110 114 113 111 115
water outlet heating efficiency) E F
55°C Seasonal space heating A+
eff. class 3.23 F 3.08 G
Average General SCOP 2.99 3.29 3.34
climate ŋs (Seasonal space % 117 126 129 120 131 130 VENTILATION & BID- DLE AIR CURTAINS
water outlet heating efficiency) G
35°C Seasonal space heating A A+ A A+
eff. class
Domestic hot water heating General Declared load profile XL L XL L XL L XL L XL L L XL
Average ŋwh (water heating efficiency) % 95.3 90.5 95.3 90.5 95.3 90.5 87.3 84.3 87.3 84.3 84.3 87.3
climate Water heating energy efficiency class A
Indoor Unit EHVH 11S26CB9W / 16S26CB9W / 16S26CB9W / 11S26CB9W / 16S26CB9W / 16S18CB3V / MARINE TYPES
11S18CB3V 16S18CB3V 16S18CB3V 11S18CB3V 16S18CB3V 16S26CB9W
Casing Colour White
Material Precoated sheet metal
Dimensions Unit HeightxWidthxDepth mm 1,732x600x728
Weight Unit kg 126 117 128 118 128 118 126 117 128 118 118 128
Tank Water volume l 260 180 260 180 260 180 260 180 260 180 180 260
Maximum water temperature °C 65 CHILLERS
Maximum water pressure bar 10
Corrosion protection Anode
Operation range Heating Water side Min.~Max. °C 15 ~55.0
Domestic Water side Min.~Max. °C 25~60 / 60
hot water
Sound power level Nom. dBA 42.0 44.0 42.0 44.0
Sound pressure level Nom. dBA 28.0 30.0 28.0 30.0 FAN COIL UNITS
Outdoor Unit ERHQ-B 011BV3 014BV3 016BV3 011BW1 014BW17 016BW1
Dimensions Unit HeightxWidthxDepth mm 1,170x900x320 1,345x900x320
Weight Unit kg 102 108
Compressor Quantity 1
Type Hermetically sealed scroll compressor
Operation range Cooling Min.~Max. °CDB 10.0~46.0 AIR HANDLING UNITS
Domestic hot water Min.~Max. °CDB -20 ~35
Refrigerant Type R-410A
GWP 2,087.5
Charge kg 2.7 3.0
Charge TCO2Eq 5.6 6.3
GWP 2,087.5
Sound power level Heating Nom. dBA 64 66 64 66 REFRIGERATION
Cooling Nom. dBA 64 66 69 64 66 69
Sound pressure Heating Nom. dBA 49 51 53 51 52
level Cooling Nom. dBA 50 52 54 50 52 54
Power supply Name/Phase/Frequency/Voltage Hz/V V3/1~/50/230 W1/3N~/50/400
Current Recommended fuses A 32 20
(1) Cooling Ta 35°C - LWE 18°C (DT = 5°C); heating Ta DB/WB 7°C/6°C - LWC 35°C (DT = 5°C) (2) Cooling Ta 35°C - LWE 7°C ( DT = 5°C); heating Ta DB/WB 7°C/6°C - LWC 45°C ( DT = 5°C )
(3) Contains fluorinated greenhouse gases CONTROL SYSTEMS
