INTRODUCTION

CO Condensing Units
2
Standard Condensing units

Standard condensing units with transcritical cycle AIR PURIFIER

› Chassis in galvanized and painted steel sheet. Bodyworking and
soundproofing available
› High modular concept.
› The gascooler can be disconnected from the unit
› Electrical board with all the necessary electronics for the operation HEATING
of the unit
› 1 MT compressor
› (Optional) Frequency drive
› All piping done in stainless steel
› Multiple options possible to facilitate transport of the unit SPLIT
› All necessary safety devices
› 3 air exit configurations
› Reduced dimensions
› Easy to transport
› Until 6 assembly options
SKY AIR

VRV
FNV42

F-Gas Free Switchboard
VENTILATION & BID- DLE AIR CURTAINS

Plug&Play Electronic Control

Heating
Proportional Interchanger MARINE TYPES
Modulation (Optional) FNV58

Protective Case
CHILLERS

FAN COIL UNITS

MT 1 comp.

FC17 7 kW
FC17
832 mm 9 kW
832 mm
FNV42 18 kW AIR HANDLING UNITS
FC17
832 mm 22 kW
1.560 mm
FC17 38 kW
FNV58
832 mm
1.560 mm 45kW
Conditions: LT: Tev.: -35°C SH: 8°K REFRIGERATION
MT: Tev.: -10°C SH: 8°K
Clime: Tev. med: 5°C SH: 8°K

LT MT Clime Global MSC Mechanical PC Parallel Heating Axial Radial CONTROL SYSTEMS
compressor
subcooler
interchanger
