Options - D-AHU Professional

Construction type SP 65 SP 45
Anodized aluminium standard standard
Profile
Anodized aluminium with thermal break option option
Corner Glass fibre reinforced nylon standard standard AIR PURIFIER
3
Polyurethane foam density 40 kg/m thermal
conductivity 0.022 W/m*K fire reaction standard standard
Panel insulation class b-s2, diam. as per EN13501-1
Mineral wool density 120 kg/m thermal
3
conductivity 0.036 W/m*K (referred to 20°C) fire option option
reaction class A1 as per EN 135011
Pre-coated galvanized steel standard standard
Aluzinc standard standard HEATING
External sheet material Galvanized steel option option
Aluminium option option
AISI 316 stainless steel option option
Pre-coated galvanized steel option option
Aluzinc standard standard
Internal sheet material SPLIT
Aluminium option option
AISI 316 stainless steel option option
Aluminium up to 30,000 m³/h standard standard
Base frame
Galvanized steel from 30,000 m³/h standard standard
Handle Glass fibre reinforced nylon standard standard SKY AIR
Compression type standard standard
Type Hinge function type option option
(possibility to remove door)

VRV

VENTILATION & BID- DLE AIR CURTAINS

Customised regulation

and control systems MARINE TYPES

All Modular air handling systems come with a regulation
and control system (with or without connection to a BMS).
CHILLERS

The MicroTech III controller is designed to work with most applications. It can
thus manage a chilled water system or direct-expansion system while providing
management of the heat recovery loop for constant or variable speeds.
This allows for precise temperature control based on P.I.D. regulation, and cons-
tantly optimises the operating parameters of the air handling unit. FAN COIL UNITS

› LCD display with 164 x 44 pixels. › Password-controlled access
› 3-key control panel. for configuration changes.
› Rotating knob control for › Maintenance reports showing
greater ease of use. all run-time hours and general The POL638 standard software has UNITS
› Memory for data backups. operating conditions. been customised to manage the AIR HANDLING
› Alarm relays for general › Alarm log to facilitate the control signals of Daikin’s ERQ and
types of incidents. analysis of incidents. VRV IV systems.
The MicroTech III controller provides the option of controlling the set-points for
ambient air temperature, air return and supply air, and the possibility of regula-
ting air quality with the addition of a CO₂ probe. For additional information about REFRIGERATION
these features, please contact your Daikin representative.
