Gas injection advantage SKY AIR

Higher capacity at low ambient
The Daikin Altherma 3 11-16 kW outdoor unit
is equipped with a new gas injection scroll
compressor allowing the unit to operate down
to -28°C outside temperature. VRV

Moreover, the heating capacity at low ambient
temperature (-7/35°C) sees an improvement of
35% compared to its predecessor.
VENTILATION & BID- DLE AIR CURTAINS

MARINE TYPES
H O
2
Convenient for sensitive

urban areas

Low sound installer setting CHILLERS
In order to fulfill the requirements of the most
sound sensitive urban areas, the installer can set
up the unit in low sound mode that reduce the
sound level by -3 dB(A).
FAN COIL UNITS

Higher performances

Leaving water temperature Daikin Altherma 3 11-14-16 kW outdoor unit

With a leaving water temperature of 60°C at -10°C The outdoor unit EPGA-D is available in size 11-14-16 kW 1 phase AIR HANDLING UNITS
outside, the Daikin Altherma 3 11-14-16 kW is perfect: and is connectable to:
• For new build applications using underfloor heating; • EAB(H/X)-D wall mounted indoor units;
• For renovation applications using radiators. • EAV(H/X)-D tank integrated floor standing indoor units;
• EAVZ-D tank integrated and Bi-Zone floor standing indoor units.
A + REFRIGERATION
Top energy performances up to
A +++ A
Thanks to the use of R-32, the unit
reaches the highest energy performances A ++ B
represented by the best energy labels. CONTROL SYSTEMS
