NEW GSIEKA

Electrical heater for VAM

AIR PURIFIER
› Total solution for fresh air with Daikin supply of both VAM
and electrical heaters
› Increased comfort in low outdoor temperature thanks
to the heated outdoor air
› Integrated electrical heater concept
(no additional accessories required) HEATING
› Standard dual flow and temperature sensor
› Flexible setting with adjustable setpoint
› Increased safety with 2 cut-outs: manual & automatic

SPLIT

SKY AIR

VRV

VENTILATION & BID- DLE AIR CURTAINS

GSIEKA 10009 15018 20024 25030 35530 (1) MARINE TYPES
Capacity kW 0.9 1.8 2.4 3.0 3.0
Duct diameter mm 100 150 200 250 355
VAM650J,
Connectable VAM VAM150FC9 VAM250FC9 VAM350,500J VAM800J, VAM1500J,
VAM2000J
VAM1000J
CHILLERS
GSIEKA10009 GSIEKA15018 GSIEKA20024 GSIEKA25030 GSIEKA35530
Height mm 171 221 271 321 426
Dimensions Depth mm 100 150 200 250 355
Width mm 370 370 370 370 373
m/s 1.5
Minimum air velocity / airflow
m³/h 45 100 170 265 535
Power supply 1~230 VAC/50Hz FAN COIL UNITS
Nominal current A 4.1 8.2 10.9 13.1 13.1
Heating power kW 0.9 1.8 2.4 3.0 3.0
Connection duct diameter mm 100 150 200 250 355
Min. °C -40°C
Operation range Max. °C 40°C
Rel. Humidity % 90%
Temperature sensor 10 kΩ at +25°C / TJ-K10K AIR HANDLING UNITS
Temperature sensor range - 30°C to 105°C
Temperature set point range - 10°C to 50°C
flashing every 5 seconds heater is starting up
flashing every second air flow detected, heating allowed
LED 1
LED indicators OFF no power supply or no flow
ON problem with duct temperature sensor, set point potentiometer or PTC airflow sensor REFRIGERATION
OFF heater is not operation
LED 2
ON heater is operating
Ambient temperature adjacent to controller 0°C to +50°C
Auto high temperature cut-out 50°C
Manual reset high temperature cut-out 100°C
