INTRODUCTION

EHBH-CB + ERHQ-BV3/ERHQ-BW1(7)

Daikin Altherma R W

Wall mounted heating only air to water heat pump
ideal for low energy houses AIR PURIFIER

› Wall mounted indoor unit
› Perfect fit for new built as well as for low energy houses
› Best seasonal efficiencies, providing the highest savings
on running costs HEATING
› Flexible configuration with respect to heat emitters
› Possible to combine with domestic hot water
› Outdoor unit extracts heat from the outdoor air, even at -20°C EHBH-CB
› Daikin Residential controller (optional)
› Possible to connect to photovoltaïc solar panels to provide
energy for your heat pump (optional) SPLIT

A +++ ERHQ011-016BW1
A ++
up to SKY AIR
A + 55°C
A

B

C VRV
D

E
Efficiency data EHBH + ERHQ-B 11CB3V + 11CB9W 16CB3V + 16CB9W 16CB3V + 16CB9W 11CB3V + 11CB9W 16CB3V + 16CB9W + 16CB3V + 16CB9W
011BV3 + 011BV3 014BV3 + 014BV3 016BV3 + 016BV3 011BW1 + 011BW1 014BW17 014BW17 016BW1 + 016BW1 VENTILATION & BID- DLE AIR CURTAINS
F
Heating capacity Nom. kW 11.2 (1) / 10.3(2) 14.0 (1) / 13.1(2) 16.0 (1) / 15.2(2) 11.3 (1) / 11.0(2) 14.5 (1) / 13.6(2) 16.1 (1) / 15.1(2)
Power input Heating Nom. kW 2.55 (1) / 3.17(2) 3.26 (1) / 4.04(2) 3.92 (1) / 4.75(2) 2.63 (1) / 3.24(2) 3.42 (1) / 4.21(2) 3.82 (1) / 4.69(2)
G
COP 4.39 (1) / 3.25(2) 4.29 (1) / 3.24(2) 4.08 (1) / 3.20(2) 4.30 (1) / 3.39(2) 4.24 (1) / 3.22(2) 4.20 (1) / 3.22(2)
Space heating Average General SCOP 2.86 2.82 2.92 2.90 2.86 2.96
climate ŋs (Seasonal space % 112 110 114 113 111 115
water outlet heating efficiency)
55°C Seasonal space heating eff. class A+ MARINE TYPES
Average General SCOP 2.99 3.23 3.29 3.08 3.34 3.33
climate ŋs (Seasonal space % 117 126 129 120 131 130
water outlet heating efficiency)
35°C Seasonal space heating eff. class A A+ A A+
Indoor Unit EHBH 11CB3V 11CB9W 16CB3V 16CB9W 16CB3V 16CB9W 11CB3V 11CB9W 16CB3V 16CB9W 16CB3V 16CB9W
Casing Colour White
Material Precoated sheet metal CHILLERS
Dimensions Unit HeightxWidthxDepth mm 890x480x344
Weight Unit kg 43.0 44.0 45.0 44.0 45.0 43.0 44.0 45.0 44.0 45.0
Operation range Heating Water side Min.~Max. °C 15 ~55.0
Domestic Water side Min.~Max. °C 25~80
hot water
Sound power level Nom. dBA 41.0 44.0 41.0 44.0
Sound pressure level Nom. dBA 27.0 30.0 27.0 30.0 FAN COIL UNITS
Outdoor Unit ERHQ-B 011BV3 014BV3 016BV3 011BW1 014BW17 016BW1
Dimensions Unit HeightxWidthxDepth mm 1,170x900x320 1,345x900x320
Weight Unit kg 102 108
Compressor Quantity 1
Type Hermetically sealed scroll compressor
Operation range Cooling Min.~Max. °CDB 10.0~46.0 AIR HANDLING UNITS
Domestic hot water Min.~Max. °CDB -20 ~35
Refrigerant Type R-410A
GWP 2,087.5
Charge kg 2.7 3.0
Charge TCO2Eq 5.6 6.3
GWP 2,087.5
Sound power level Heating Nom. dBA 64 66 64 66 REFRIGERATION
Cooling Nom. dBA 64 66 69 64 66 69
Sound pressure Heating Nom. dBA 49 51 53 51 52
level Cooling Nom. dBA 50 52 54 50 52 54
Power supply Name/Phase/Frequency/Voltage Hz/V V3/1~/50/230 W1/3N~/50/400
Current Recommended fuses A 32 20
(1) Cooling Ta 35°C - LWE 18°C (DT = 5°C); heating Ta DB/WB 7°C/6°C - LWC 35°C (DT = 5°C) (2) Cooling Ta 35°C - LWE 7°C ( DT = 5°C); heating Ta DB/WB 7°C/6°C - LWC 45°C ( DT = 5°C )
(3) Contains fluorinated greenhouse gases CONTROL SYSTEMS
