INTRODUCTION

EHSXB-B + ERLQ-CV3/ERLQ-CW1

Daikin Altherma R ECH O
2

Floor standing air to water heat pump
for bivalent heating, cooling and hot water AIR PURIFIER
with thermal solar support

› Bivalent system: combinable with a secondary heat source

HEATING

SPLIT

Options 011-1W0096  104
Type Material name EHSXB-B ERLQ011-016CW1
Room thermostat RoCon U1 EHS157034 A +++ A +
Controls Gateway RoCon G1 for apps EHS157056
Connection kit for MK1 VMK1 ++ SKY AIR
Back-up heater 1kW EKBU1C A A 55°C
Back-up heater Back-up heater 3kW EKBU3C
Back-up heater 9kW EKBU9C A + B
Heat insulation for hydraulic separator (HWC) WHWC
Installation Separator for dirt SAS1
Separator - hydraulic HWC A C
External sensor EKRTETS
Sensor VRV
Outdoor sensor for Rocon Controller RoCon OT1 B D
Others Mixer module RoCon M1 EHS157068
C E
Efficiency data EHSXB + ERLQ-C 16P50B + 16P50B + 16P50B + 16P50B + 16P50B + 16P50B +
011CV3 014CV3 016CV3 011CW1 014CW1 016CW1
D
F
Heating capacity Nom. kW 5.95(1) / 7.74(2) / 14.81(1) / 13.73(2) / 15.34(1) / 14.86(2) / 5.95(1) / 7.74(2) / 8.28(1) / 9.57(2) / 8.04 / 10.05 / 15.34
11.80(3) / 10.40(4) 8.28(3) / 9.57(4) 8.04(3) / 10.05(4) 11.80(3) / 10.40(4) 14.81(3) / 13.73(4) / 14.86
Cooling capacity Nom. kW 15.1(1) / 11.7(2) 16.1(1) / 12.6(2) 16.8(1) / 13.1(2) 15.1(1) / 11.7(2) 16.1(1) / 12.6(2) 16.8 / 13.1 VENTILATION & BID- DLE AIR CURTAINS
E
G
Power input Heating Nom. kW 2.57 / 3.13 3.42(1) / 4.07(2) / 3.17(3) / 2.93(4) 2.57(1) / 3.13(2) / 3.42(1) / 4.07(2) / 3.42 / 4.07 / 3.17
/ 2.43 / 2.35 2.43(3) / 2.35(4) 3.17(3) / 2.93(4) / 2.93
Cooling Nom. kW 4.55(1) / 4.30(2) 4.27(1) / 3.34(2) / F 6.18(1) / 5.72(2) 4.55(1) / 4.30(2) 5.44(1) / 5.10(2) 6.18 / 5.72
5.44(1) / 5.10(2)
COP 4.38(1) / 3.32(2) / 4.10(1) / 3.22(2) / 4.38(1) / 3.32(2) / 4.27(1) / 3.34(2) / 4.10 / 3.22 / 2.44
2.45(3) / 3.29(4) 2.58(3) / 3.22(4) 2.44(3) / 3.15(4) 2.45(3) / 3.29(4) 2.58(3) / 3.22(4) / 3.15
130 G
EER 3.32(1) / 2.72(2) 2.96(1) / 2.47(2) 2.72(1) / 2.29(2) 3.32(1) / 2.72(2) 2.96(1) / 2.47(2) 2.72 / 2.29
Space heating Average General ŋs (Seasonal space % 128 127 128 130 127
climate water heating efficiency) MARINE TYPES
outlet 55°C Seasonal space heating eff. class A++
Domestic hot water General Declared load profile XL
heating Average ŋwh (water heating efficiency) % 84
climate Water heating energy efficiency class A
Indoor Unit EHSXB 16P50B 16P50B 16P50B 16P50B 16P50B 16P50B
Casing Colour Traffic white (RAL9016) / Dark grey (RAL7011)
Material Impact resistant polypropylene
Dimensions Unit HeightxWidthxDepth mm 1,890x790x790 CHILLERS
Weight Unit kg 118
Tank Water volume l 477
Maximum water temperature °C 85
Operation range Heating Ambient Min.~Max. °C -25~35
Water side Min.~Max. °C 15 ~55
Cooling Ambient Min.~Max. °CDB 10~43
Water side Min.~Max. °C -~-
Domestic Ambient Min.~Max. °CDB -25~35 FAN COIL UNITS
hot water Water side Min.~Max. °C 25~55
Sound power level Nom. dBA 40
Sound pressure level Nom. dBA 28
Outdoor Unit ERLQ-C 011CV3 014CV3 016CV3 011CW1 014CW1 016CW1
Dimensions Unit HeightxWidthxDepth mm 1,345x900x320
Weight Unit kg 113 114
Compressor Quantity 1 AIR HANDLING UNITS
Type Hermetically sealed scroll compressor
Operation range Cooling Min.~Max. °CDB 10.0~46.0
Domestic hot water Min.~Max. °CDB -20 ~35
Refrigerant Type R-410A
GWP 2,087.5
Charge kg 3.4
Charge TCO2Eq 7.1
Control Expansion valve (electronic type) REFRIGERATION
Sound power level Heating Nom. dBA 64 66 64 66
Cooling Nom. dBA 64 66 69 64 66 69
Sound pressure level Heating Nom. dBA 51 52 51 52
Cooling Nom. dBA 50 52 54 50 52 54
Power supply Name/Phase/Frequency/Voltage Hz/V V3/1~/50/230 W1/3N~/50/400
Current Recommended fuses A 40 20
(1) Cooling Ta 35°C - LWE 18°C (DT = 5°C); heating Ta DB/WB 7°C/6°C - LWC 35°C (DT = 5°C) (2) Cooling Ta 35°C - LWE 7°C ( DT = 5°C); heating Ta DB/WB 7°C/6°C - LWC 45°C ( DT = 5°C )
(3) EW 30°C; LW 35°C; ambient conditions: -7°CDB/-8°CWB (4) EW 30°C; LW 35°C; ambient conditions: 2°CDB/1°CWB (5) Contains fluorinated greenhouse gases CONTROL SYSTEMS
