FXAQ-A

Wall mounted unit

For rooms with no false ceilings nor free floor space AIR PURIFIER

› Flat, stylish front panel blends easily within any interior décor and
is easier to clean
› Can easily be installed in both new and refurbishment projects
› The air is comfortably spread up- and downwards thanks to
5 different discharge angles that can be programmed via the HEATING
remote control FXAQ-A
› Maintenance operations can be performed easily from the front of
the unit

SPLIT

BRC1H519W7, BRC7EA628
SKY AIR

VRV

VENTILATION & BID- DLE AIR CURTAINS

MARINE TYPES

CHILLERS

Access all technical information on FXAQ-A
at my.daikin.eu or click here
Indoor unit FXAQ 15A 20A 25A 32A 40A 50A 63A FAN COIL UNITS
Cooling capacity Total capacity Nom. kW 1.7 2.2 2.8 3.6 4.5 5.6 7.1
Heating capacity Total capacity Nom. kW 1.9 2.5 3.2 4.0 5.0 6.3 8.0
Power input - 50Hz Cooling Nom. kW 0.02 0.03 0.02 0.03 0.05
Heating Nom. kW 0.03 0.04 0.02 0.04 0.06
Dimensions Unit HeightxWidthxDepth mm 290x795x266 290x1,050x269
Weight Unit kg 12 15
Fan Air flow rate - Cooling Low/High m³/min 7.0/8.4 7.0/9.1 7.0/9.4 7.0/9.8 9.7/12.2 11.5/14.4 13.5/18.3 AIR HANDLING UNITS
50Hz
Air filter Type Washable resin net
Sound power level Cooling High dBA 51.0 52.0 53.0 55.0 58.0 63.0
Sound pressure Cooling Low/High dBA 28.5/32.0 28.5/33.0 28.5/35.0 28.5/37.5 33.5/37.0 35.5/41.0 38.5/46.5
level Heating Low/High dBA 28.5/33.0 28.5/34.0 28.5/36.0 28.5/38.5 33.5/38.0 35.5/42.0 38.5/47.0
Refrigerant Type/GWP R-410A/2,087.5
Piping connections Liquid OD mm 6.35 9.52 REFRIGERATION
Gas OD mm 12.7 15.9
Drain VP13 (I.D. 15/O.D. 18)
Power supply Phase/Frequency/Voltage Hz/V 1~/50/220-240
Current - 50Hz Maximum fuse amps (MFA) A 16
Control systems Infrared remote control BRC7EA628 / BRC7EA629
CONTROL SYSTEMS
Wired remote control BRC1H519W7/S7/K7 / BRC1E53A/B/C / BRC1D52
