E(B/D)LQ-CV3

Daikin Altherma M

Reversible air to water monobloc system,
ideal when indoor space is limited

› Compact reversible monobloc for space heating
& cooling with optional domestic hot water
› Compact heating only monobloc for space heating
with optional domestic hot water
› Fuss-free installation : only water connections required
› Reliable operation even when -25°C outside thanks
to frost protection features such as free hanging coil
› COP up to 5

E(D/B)LQ-CV3

A +++

011-1W0079 A ++ 55°C
011-1W0080
A +
A

B

Single Unit EBLQ/EDLQ 05CV3 C 07CV3 05CV3 07CV3
Space heating Average General ηs (Seasonal space % 125
climate heating efficiency)
water outlet SCOP 3.20 D 3.22 3.20 3.22
55°C Seasonal space heating A++
eff. class E
Average General ηs (Seasonal space % 172 163 172 163
climate heating efficiency) F
water outlet SCOP 4.39 4.14 4.39 4.14
35°C Seasonal space heating A++
eff. class G
Heating capacity Nom. kW 4.40(1) / 4.03(2) 7.00(1) / 6.90(2) 4.40(1) / 4.03(2) 7.00(1) / 6.90(2)
Cooling capacity Nom. kW 3.88(1) / 3.99(2) 5.20(1) / 5.15(2) -
Power input Cooling Nom. kW 0.950(1) / 1.93(2) 1.37(1) / 2.69(2) -
Heating Nom. kW 0.880(1) / 1.13(2) 1.55(1) / 2.45(2) 0.880(1) / 1.13(2) 1.55(1) / 2.02(2)
COP 5.00(1) / 3.58(2) 4.52(1) / 3.42(2) 5.00(1) / 3.58(2) 4.52(1) / 3.42(2)
EER 4.07(1) / 2.07(2) 3.80(1) / 2.10(2) -
Dimensions Unit HeightxWidthxDepth mm 735x1,090x350
Weight Unit kg 76.0 80.0 76.0 80.0
Operation range Heating Water side Min.~Max. °C 15 ~55.0
Cooling Ambient Min.~Max. °CDB 10.0~43.0 -~-
Water side Min.~Max. °C 5.00 ~22.0 -~-
Domestic Ambient Min.~Max. °CDB -25.0 ~35.0
hot water Water side Min.~Max. °C 25~80 25~80
Refrigerant Type R-410A
GWP 2,088
Charge kg 1.30 1.45 1.30 1.45
Charge TCO2Eq 2.714 3.027 2.714 3.027
Control Expansion valve (electronic type)
Sound power level Heating Nom. dBA 61 62 61 62
Cooling Nom. dBA 63.0 -
Sound pressure Heating Nom. dBA 48 49 48 49
level Cooling Nom. dBA 48 50 -

Wiring centre EKCB07CV3 EK2CB07CV3
Casing Colour White
Material Precoated sheet metal
Dimensions Unit HeightxWidthxDepth mm 360x340x97.0
Weight Unit kg 4.00

Back-up heater kit EKMBUHC3V3 EKMBUHC9W1
Casing Colour White
Material Precoated sheet metal
Dimensions Unit HeightxWidthxDepth mm 560x250x210
Weight Unit kg 11.0 13.0
(1) Cooling Ta 35°C - LWE 18°C (DT = 5°C); heating Ta DB/WB 7°C/6°C - LWC 35°C (DT = 5°C) (2) Cooling Ta 35°C - LWE 7°C ( DT = 5°C); heating Ta DB/WB 7°C/6°C - LWC 45°C ( DT = 5°C )
(3) Contains fluorinated greenhouse gases
