INTRODUCTION

Evaporators range

Evaporators with or without TEV

for different operations
and refrigerants AIR PURIFIER

General features:
Flat Double flow
ʯ Capacity for LT/MT cooling: 0,5 to 213 kW
ʯ Ambient/cooling room temperature range: - 40°C - +25°C HEATING
ʯ Refrigerants: R134A a, R 449A, R448A, R452A R407F, R 407A
ʯ Fin distance: from 3 mm to 11 mm
ʯ Fin materials: Al
ʯ Tube materials: Cu
ʯ Conditions: SPLIT
MT: Ambient temperature: 35°C Evp. Temperature: -10°C
LT: Ambient temperature: 35°C Evp. Temperature: -35°C

Options: Cubic

ʯ Electric defrost heating SKY AIR
ʯ Hot gas defrost Types:
ʯ Drain pan heating
ʯ Fan ring heater › flat evaporator › Evaporator only
ʯ High efficient EC fans › double flow › Evaporator + EEV/TEV
ʯ Wiring on terminal box › cubic design › Evaporator + EEV/TEV + electronic
ʯ Included valves and regulation controller VRV
ʯ Fin materials AISI 304, AISI 316
ʯ Tube materials AISI 304, AISI 316
ʯ Casing in stainless steel (Inox) For technical selection, prices, accessories and delivery time please use the Zanotti
software and contact our technical department. We are happy to help you.
VENTILATION & BID- DLE AIR CURTAINS

Dimensions

mm A B C
Flat
201 215 614 410
202 215 1034 410
203 215 1614 410 MARINE TYPES
232 150 713 455
301 300 910 690
302 300 1530 690
303 300 2150 690
304 300 2770 690
305 300 3390 690
CHILLERS

Double flow
D E
mm A B C D E
231 171 579 585 293 600 FAN COIL UNITS
889
A 232 171 1199 585 603 600
233
600
913
171
585
234 171 1509 585 1223 600
352 300 1671 995 1214 1065
353 300 2291 995 1834 1065
AIR HANDLING UNITS
B C 354 300 2911 995 2454 1065
300
1065
995
3074
3531
355
mm A B C D E
Cubic
301 420 480 789 495 345
960
E D 302 420 480 1254 1425 345
1719
345
303
420
480
HEU351 545 690 805 605 540
HEU352 530 690 1220 965 540 REFRIGERATION
HEU353 600 690 1690 1370 540
HEU403 620 700 1840 1520 545
HEU502 844 992 1829 1526 740
SKC352 490 606 1614 1270 450
SKC353 490 606 2234 1890 450
SKC452 610 650 2032 1680 510
SKC503 800 830 3350 2760 675 CONTROL SYSTEMS
713
