INTRODUCTION

CU Series

Condensing unit for outdoor

installation with hermetic
compressors AIR PURIFIER

General features:
CU1
› Capacity for MT cooling: 0,9 kW to 26,7 kW
› Capacity for LT cooling: 0,6 kW to 12 kW HEATING
› Ambient temperature range : - 25°C - +43°C
› R134A a, R 449A, R448A, R452A R407F, depending on
the compressor
› Tecumseh, Maneurop, Copeland scroll
› Conditions: SPLIT
MT: Ambient temperature: 35°C Evp. Temperature: -10°C
LT: Ambient temperature: 35°C Evp. Temperature: -35°C
CU3
General Description:

Compact air cooled condensing unit floor SKY AIR
mounting, low noise, with hermetic compressors.
Designed specifically for small capacity refrigeration Standard characteristics:
applications in small food stores (eg. in bakeries and
butchers), cold rooms, bottle coolers and display › Hermetic compressor with integral protection
cabinets. All components can be accessed, allowing › Dual HP/LP fixed switch with auto reset
for quick and easy maintenance. › Liquid line filter dryer, liquid line sight glass VRV
The optimized compressor range and increased › Curved condenser with 6-pole fan motor
condenser surface deliver high levels of energy › Liquid receiver with safety pressure relief valve for
efficiency and reliability is ensured by using high PED units (depending on the model & PED class)
quality components and production processes. › Electrical box with capacity controller (only for
VENTILATION & BID- DLE AIR CURTAINS
digital scroll)
› Crankcase heater (only scroll type)

Normal cooling
Condensing unit GCU-E 1006U01 107U01 1010U01 1012U01 1015U01 2025U01 2028U01 2035U01 2040U01E
Refrigeration capacity 0° C W 1,428 1,704 2,097 2,470 3,162 5,186 6,102 7,350 7,557
-10° C W 974 1,177 1,498 1,710 2,075 3,013 3,848 4,628 5,173 MARINE TYPES
Power input kW 0.61 0.7 0.83 0.88 1.2 1.53 1.82 2.17 2.67
COP 32°C (1) 1.59 1.67 1.8 1.93 1.72 1.96 2.11 2.13 1.94
COP 25°C (1) 1.84 1.93 2.07 2.23 1.98 2.23 2.4 2.42 2.2
COP 43°C (1) 1.23 1.31 1.5 1.53 1.35 1.55 1.66 1.68 1.55
- - - - - - - - 2.4
SEPR(1)
Annual Electricity Consumption(1) Kwh/a - - - - - - - - 13,257
Dimensions Unit Height mm 625 625 625 625 625 800 800 800 800 CHILLERS
Width mm 1150 1150 1150 1150 1150 1400 1400 1400 1400
Depth mm 500 500 500 500 500 550 550 550 550
Condenser air flow m³/h 1,840 1,840 1,840 1,830 1,830 3,600 3,600 3,600 3,370
Compressor Tecumseh reciprocating hermetic compressor
Refrigerant Type/GWP R-134A/1430
Power supply V/~/ Hz 230/1~/50 400/3~/50
Deep freezing FAN COIL UNITS
Condensing unit HCU-D 1010U01 1012U01 1015U01 1017U01 1020U01 2025U01 2035U01
Refrigeration capacity -25° C W 673 778 1,058 1,323 1,790 2,597 (2)
-35° C W 377 449 626 802 1,021 1,481 (2)
Power input kW 0.45 0.53 0.62 0.85 1.2 1.41 (2)
COP 32°C (1) 0.83 0.85 1 0.94 0.85 1.05 (2)
COP 25°C (1) 0.98 0.99 1.16 1.09 1 1.22 (2) AIR HANDLING UNITS
COP 43°C (1) 0.62 0.64 0.76 0.73 0.59 0.79 (2)
- - - - - - (2)
SEPR(1)
Annual Electricity Consumption(1) Kwh/a - - - - - - (2)
Dimensions Unit Height mm 625 625 625 625 625 800 800
Width mm 1150 1150 1150 1150 1150 1400 1400
Depth mm 500 500 500 500 500 550 550
Condenser air flow m³/h 1,840 1,840 1,840 1,840 1,830 3,600 (2) REFRIGERATION
Compressor Tecumseh reciprocating hermetic compressor
Refrigerant Type/GWP R-452A/2141
Power supply V/~/ Hz 230/1~/50 400/3~/50
Other refrigerants, compressors and options available on request (1) Nominal operating conditions according to Ecodesign EN 13215: Ambient temperature 32°C/25°C/43°C, Evaporation temperature -10°C -35°C,
20°C suction gas temperature, Sub cooling 0K; (2) Not existing at the moment
CONTROL SYSTEMS
