Options & accessories - indoor & hot water

Concealed ceiling units (duct units) Ceiling suspended units Wall mounted units Floor standing units
High ESP High ESP 1-way blow 4-way blow Concealed Free-standing
FXMQ 50~80 FXMQ 100~125 FXMQ 200~250 FXHQ 32A FXHQ 63A FXHQ 71~100A FXUQ-A FXAQ-A FXNQ-A FXLQ 20~25 FXLQ 32~40 FXLQ 50~63
Decoration panel EKRDP25A EKRDP40A EKRDP63A
(obligatory for cassette units, optional for others, rear panel for FXLQ)
Panels Panel spacer for reducing required installation height KDBHP49B140 + KDBTP49B140
Sealing kit for 3- or 2-directional air discharge
Sensor kit
Infrared remote control including receiver BRC4C65 BRC4C65 BRC4C65 BRC7GA53-9 BRC7GA53-9 BRC7GA53-9 BRC7C58 BRC7EA628 BRC4C65 BRC4C65 BRC4C65 BRC4C65
Individual control systems BRC1H519W(7) (White) / BRC1H519S(7) (Silver) / BRC1H519K(7) (Black) • • • • • • • • • • • • • • • • • • • • •
Madoka
User-friendly wired remote controller with premium design
•
•
•
BRC1E53A/B/C - Wired remote control with full-text interface and
back-light
BRC1D52 (4) - Standard wired remote control with weekly timer • • • • • • • • • • • • • • • • • • • • •
•
•
•
DCC601A51 - Intelligent Tablet Controller
Centralised control systems DCS601C51 (12) - intelligent Touch Controller • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
•
•
•
DCS302C51 (12) - Central remote control
•
•
•
DCS301B51 (12) (13) - Unified ON/OFF control
•
•
•
DST301B51 (12) - Schedule timer
Building management system + standard protocol interface DCM601A51 - Intelligent Touch Manager • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
•
•
•
EKMBDXA - DIII-net modbus interface
•
•
KLIC-DI - KNX interface
•
•
•
DMS502A51 - BACnet interface
•
•
•
•
DMS504B51 - LowWorks interface
Replacement long life filter, non-woven type • • • KAFP501A56 KAFP501A80 KAFP501A160 KAFP551K160 • • • • •
Filters Auto cleaning filter
Wiring and sensors KRCS - External wired temperature sensor KRCS01-4 KRCS01-4 KRCS01-1 KRCS01-4 KRCS01-4 KRCS01-4 KRCS01-4 KRCS01-1B KRSC01-4 KRCS01-1 KRCS01-1 KRCS01-1
•
•
•
•
•
•
•
•
•
•
•
•
K.RSS - External wireless temperature sensor
(14)
Adapter with 2 output signals
(Compressor / Error, Fan output) KRP1B54 KRP1B54 KRP1B54
Adapter with 4 output signals EKRP1B2 EKRP1B2 KRP1B61 KRP1B56 KRP1B56 KRP1B61 KRP1B61 KRP1B61
(Compressor / Error, Fan, Aux. heater, Humidifier output)
Adapter for centralised external monitoring/control via dry contacts
and setpoint control via 0-140Ω KRP4A51 KRP4A51 KRP4A51 KRP4A52 (2) KRP4A52 (2) KRP4A52 (2) KRP4A53 (2) KRP4AA51 (2) KRP4A54-9 KRP4A51 KRP4A51 KRP4A51
Adapters Adapter for external central monitoring/control KRP2A51 KRP2A51 KRP2A51 KRP2A62 (2) KRP2A62 (2) KRP2A62 (2) BRP7A53 KRP2A51 / KRP2A61(2) KRP2A53 KRP2A51 KRP2A51 KRP2A51
(controls 1 entire system)
BRP7A51
BRP7A51
BRP7A51
BRP7A51
BRP7A52
BRP7A51
BRP7A51
BRP7A51
BRP7A52
BRP7A52
Adapter for keycard and/or window contact connection (2)(11)
Adapter for multi-tenant applications
(24VAC PCB power supply interface) DTA114A61 DTA114A61 DTA114A61 DTA114A61 EKMTAC EKMTAC EKMTAC
External control adapter for outdoor unit (installation on indoor unit) DTA104A61 DTA104A61 DTA104A61 DTA104A62 DTA104A62 DTA104A62 DTA104A51 / DTA104A61
Installation box / Mounting plate for adapter PCBs
(For units where there is no space in the switchbox) KRP4A96 KRP4A96 KRP1D93A KRP1D93A KRP1D93A KRP1B97 KRP4AA93 (16)(17)
Wiring kit for Remote ON/OFF or Forced OFF Standard Standard Standard EKRORO4 EKRORO4 EKRORO4 EKRORO5 Standard Standard Standard Standard Standard
Drain pump kit Standard Standard KDU30M250 KDU50P60 KDU50P140 KDU50P140
Multi zoning kit (for detailed model code overview refer to
Others multizoning argue card in this catalogue) KDDQ50A140 KDDQ50A140 KDDQ50A140 K-KDU572EVE
Fresh air intake kit (direct installation type)
Air discharge adapter for round duct KDAJ25K71 KDAJ25K140
Filter chamber for bottom suction KHFP5M35 KHFP5N63 KHFP5N160
(1) pump station is necessary for this option
(2) Installation box is necessary for these adapters
(3) The BYCQ140EW has white insulation. Be informed that formation of dirt on white insulation is visibly stronger and that it is consequently not advised to install the BYCQ140E decoration panel in
environments exposed to concentrations of dirt”
(4) Not recommended because of the limitation of the functions
(5) To be able to control the BYCQ140EGF(B) the controller BRC1E is needed
(6) The BYCQ140EGF(B) is not compatible with Multi and Split Non-Inverter Outdoor units
(7) Option not available in combination with BYCQ140EGF(B)
(8) Both parts of the fresh air intake are needed for each unit
(9) Cannot be combined with sensor kit
(10) Independently controllable flaps function not available
(11) Only possible in combination with BRC1H* / BRC1E*
(12) When fixing box is required, use KJB212A, KJB311A or KJB411A depending on the size of the controller
(13) Option KEK26-1A (Noise filter) is required when installing DCS301B51
(14) Wire harnass EKEWTSC is necessary
(15) The active airflow circulation function is not available for this controller.
(16) Up to 2 adaptor PCBs can be installed per installation box
(17) Only one installation box can be installed per indoor unit
