NEW FXDA-A INTRODUCTION

Slim concealed ceiling unit rear
suction

Slim design for flexible installation AIR PURIFIER

› Optimised design for R-32 refrigerant
› 10 class unit especially developed for small or well-insulated outblow
rooms, such as hotel bedrooms, small offices, etc.
› Compact dimensions, can easily be mounted in a ceiling void of bottom
suction
only 240mm HEATING
SERIE A (15, 20, 25, 32) FXDA-A

200 mm

700 mm
50 mm SPLIT
› Medium external static pressure up to 44Pa facilitates unit use
with flexible ducts of varying lengths
› Discretely concealed in the wall: only the suction and discharge BRC1H52W, BRC4C65
grilles are visible
› Optional auto cleaning filter option ensures maximum efficiency, SKY AIR
comfort and reliability by regular filter cleaning
› Flexible installation, as the air suction direction can be altered
from rear to bottom suction

VRV

VENTILATION & BID- DLE AIR CURTAINS
› Standard drain pump with 750mm lift increases flexibility and
installation speed

750 mm
MARINE TYPES

Access all technical information on FXDA-A
at my.daikin.eu or click here
Access all technical information on BAE20A CHILLERS
at my.daikin.eu or click here Auto cleaning filter option
Indoor unit FXDA 10A 15A 20A 25A 32A 40A 50A 63A
Cooling capacity Total capacity Nom. kW 1.10 1.70 2.20 2.80 3.60 4.50 5.60 7.10
Heating capacity Total capacity Nom. kW 1.30 1.90 2.50 3.20 4.00 5.00 6.30 8.00
Power input - 50Hz Cooling Nom. kW 0.062 0.071 0.078 0.099 0.110 FAN COIL UNITS
Heating Nom. kW 0.058 0.068 0.075 0.096 0.107
Required ceiling void > mm 240
Dimensions Unit HeightxWidthxDepth mm 200x750x620 200x950x620 200x1,150x620
Weight Unit kg 22.5 22.0 26.0 29.0
Casing Material Galvanised steel
Fan Air flow rate - 50Hz Cooling Low/High m³/min 4/5.7 6.4/7.5 6.4/8.0 8.5/10.5 10.0/12.5 13.0/16.5
External static Nom./High Pa 10/30.0 15/44.0 AIR HANDLING UNITS
pressure - 50Hz
Air filter Type Removable / washable
Sound power level Cooling High dBA 48 50 51 52 53 54
Sound pressure level Cooling Low/Nom./High dBA 24/26/27 27.0/31.0/32.0 27.0/31.0/33.0 28.0/32.0/34.0 29.0/33.0/35.0 30.0/34.0/36.0
Refrigerant Type/GWP R-32 / 675
Piping connections Liquid OD mm 6.35 9.52
Gas OD mm 12.7 15.9 REFRIGERATION
Drain VP20 (I.D. 20/O.D. 26)
Power supply Phase/Frequency/Voltage Hz/V 1~/50/60/220-240/220
Current - 50Hz Maximum fuse amps (MFA) A 16
Control systems Infrared remote control BRC4C65 / BRC4C66
Wired remote control BRC1H52W/S/K
CONTROL SYSTEMS
*Note: blue cells contain preliminary data
