INTRODUCTION

EHYHBH-AV32/EHYHBX-AV3 + EVLQ-CV3

Daikin Altherma R Hybrid

Hybrid technology combining condensing gas
and air to water heat pump for heating and hot water AIR PURIFIER

› Heating only + heating and cooling models
› Depending on outdoor temperature, energy prices and internal
heat load, Daikin Altherma hybrid heat pump always selects
the most economical mode to operate HEATING
› Low investment cost: no need to replace the existing radiators
(up to 80°C) and pipe work EVLQ-CV3
› Provides sufficient heat in renovation applications as all heat
loads are covered up to 32kW
› Easy and fast installation thanks to the compact dimensions
and quick interconnections SPLIT

EHYHBH-AV32
A +++ A +

A ++ A 55°C

011-1W0313 + SKY AIR
011-1W0314 A B
A
3.24 C
Efficiency data EHYHBH05AV32 + EVLQ05CV3 EHYHBH08AV32 + EVLQ08CV3 EHYHBX08AV3 + EVLQ08CV3
Space heating Average General SCOP 3.28 3.29
climate water ŋs (Seasonal space % 128 127 129
outlet 55°C heating efficiency) B D
Seasonal space heating eff. class A++
XL
Domestic hot water heating General Declared load profile C 83.8 E VRV
Average ŋwh (water heating efficiency) %
climate Water heating energy efficiency class A
F
Heating capacity Nom. kW 4.40(1) / 4.03(2) D 7.40(1) / 6.89(2) 7.40(1) / 6.89(2)
Cooling capacity Nom. kW - 6.86(1) / 5.36(2)
G
Power input Heating Nom. kW 0.870(1) / 1.13(2) - E 1.66(1) / 2.01(2) 1.66(1) / 2.01(2)
Cooling Nom. kW 2.01(1) / 2.34(2)
COP 5.04(1) / 3.58(2) 4.45(1) / 3.42(2) 4.45(1) / 3.42(2) VENTILATION & BID- DLE AIR CURTAINS
EER F - 3.42(1) / 2.29(2)
Indoor unit (Hydrobox & Boiler) EHYHBH05AV32 EHYHBH08AV32 EHYHBX08AV3 EHYKOMB33AA2 EHYKOMB33AA3
-
Central heating Heat input Qn (net Nom Min/Max kW G 6.2 / 7.6 / 7.6 /22.1 / 27.0 / 27.0
calorific value)
Output Pn at 80/60°C Min/Nom kW - 6.7 / 8.2 / 8.2 /21.8 / 26.6 / 26.6
Efficiency Net calorific value % - 98 / 107
Operation range Min/Max °C - 15 /80 MARINE TYPES
Domestic hot Output Min/Nom kW - 7.6/32.7
water Water flow Rate Nom l/min - 9.0 / 15.0
Operation range Min/Max °C - 40/65
Gas Connection Diameter mm - 15
Consumption (G20) Min/Max m³/h - 0.78/3.39
Consumption (G25) Min/Max m³/h - 0.90/3.93
Consumption (G31) Min/Max m³/h - 0.30/1.29
Supply air Connection mm - 100 CHILLERS
Concentric - 1
Flue gas Connection mm - 60
Casing Colour White White - RAL9010
Material Precoated sheet metal Precoated sheet metal
Dimensions Unit HeightxWidth Casing mm 902x450x164 710x450x240
xDepth
Weight Unit Empty kg 30.0 31.2 36
Power supply Phase/Frequency/Voltage Hz/V - 1~/50/230 FAN COIL UNITS
Electrical power Max. W - 55
consumption Standby W - 2
Operation range Heating Ambient Min.~Max. °C -25 ~25 -
Water side Min.~Max. °C 25 ~55 -
Cooling Ambient Min.~Max. °CDB -~- 10 ~43 -
Water side Min.~Max. °C -~- 5 ~22 -
Outdoor unit EVLQ05CV3 EVLQ08CV3 AIR HANDLING UNITS
Dimensions Unit HeightxWidthxDepth mm 735x832x307
Weight Unit kg 54 56
Compressor Quantity 1
Type Hermetically sealed swing compressor
Operation range Heating Min.~Max. °CWB -25~25
Refrigerant Type R-410A
GWP 2,088
Charge kg 1.5 1.6 REFRIGERATION
Charge TCO2Eq 3.0 3.3
GWP 2,088
Sound power level Heating Nom. dBA 61 62
Sound pressure level Heating Nom. dBA 48 49
Power supply Name/Phase/Frequency/Voltage Hz/V V3/1~/50/230
Current Recommended fuses A 16 20
(1) Ta DB/WB 7°C/6°C - LWC 35°C (DT = 5°C) (2) Condition: Ta DB/WB 7°C/6°C - LWC 45°C (Dt=5°C) (3) Cooling Ta 35°C - LWE 18°C (DT = 5°C); heating Ta DB/WB 7°C/6°C - LWC 35°C (DT = 5°C)
(4) Cooling Ta 35°C - LWE 7°C ( DT = 5°C); heating Ta DB/WB 7°C/6°C - LWC 45°C ( DT = 5°C ) CONTROL SYSTEMS
