Standard protocol interfaces
KNX interface
KLIC-DD(3)
KLIC-DI
Integration of Split, Sky Air and VRV in HA/BMS systems
Connect split indoor units to KNX interface
for Home Automation system
light
Concept Domotica shutter control house
Interface Daikin protocol/ KNX Controller tv
Connect Sky Air / VRV indoor units to
KNX interface for BMS integration
light
Concept Domotica shutter control tv shop
Interface Daikin protocol/ KNX Controller
KNX interface line-up
The integration of Daikin indoor units through - such as “Home leave” - in which the end-user selects
the KNX interface allows monitoring and control a range of commands to be executed simultaneously
of several devices, such as lights and shutters, from once the scenario is selected. For instance in
one central controller. One particularly important “Home leave” , the air conditioner is off, the lights are
feature is the ability to programme a ‘scene’ turned off, the shutters are closed and the alarm is on.
KNX interface for
KLIC-DD (3) Size 45x45x15mm KLIC-DI Size 90x60x35mm
Split Sky Air VRV
Basic control
On/Off • • •
Mode Auto, heat, dry, fan, cool Auto, heat, dry, fan, cool Auto, heat, dry, fan, cool
Temperature • • •
Fan speed levels 3 or 5 + auto 2 or 3 2 or 3
Swing Stop or movement Stop or movement Swing or fixed positions (5)
Advanced functionalities
Error management Communication errors, Daikin unit errors
Scenes • • •
Auto switch off • • •
Temperature limitation • • •
Initial configuration • • •
Master and slave configuration • •
