Controls
3 controller versions are available to choose from:
Colour, touch or simplified
AIR PURIFIER
Blueface - main thermostat
› Intuitive graphical, colour touch screen
for controlling multiple zones
HEATING
AZCE6BLUEFACECB
(Wired)
Think - zone thermostat
› Graphic touch button with low-energy e-ink screen
for controlling single zones
SPLIT
AZCE6THINKCB (Wired)
AZCE6THINKRB (Wireless)
Lite - zone thermostat
SKY AIR
› Simplified thermostat with touch buttons for temperature control
AZCE6LITECB (Wired)
AZCE6LITERB (Wireless) › Optional bus cable (2 x 0.5 mm2 | 2 x 0.22 mm2), 10m length: AZX6CABLEBUS10, 100m length: AZX6CABLEBUS100
VRV
Webserver for remote control BACnet gateway
› Cloud based remote control of › Allows ON/OFF control of each zone VENTILATION & BID- DLE AIR CURTAINS
multizoning kit(s) AZX6BACNET › Control of temperature for each zone
› Configruation and control of zones › Status indication of operation mode
AZX6WSCLOUDDINC (Ethernet) (temperature, operation mode, ...) › One gateway needed per system
AZX6WSCLOUDDINR (WiFi)
› Access via webportal, or Android/IOS
application MARINE TYPES
Grilles and plenums
CHILLERS
Supply air grilles and plenums Return air grilles and plenums
Wall type supply grille Return air grille with
› With horizontal and vertical integrated filter
adjustable flaps › Filters particles from the air FAN COIL UNITS
RDHV040015BKX
RRFR050050BTX
Ceiling type supply grille Plenum for return grille
› With horizontal flaps angled at 15° › To connect 1 up to 4 circular ducts AIR HANDLING UNITS
› Vertical flaps can be adjusted to the return air grille
manually › Diameter 250mm
RLQV040015BKX
BR500
Plenum for supply grille Plenum for return air
› To connect circular ducts to › To connect 1 up to 4 circular ducts to REFRIGERATION
discharge grille the Daikin concealed ceiling units
PREJ0400150T AZCEZDAPR07*
› Insulated, galvanised steel › Diameter 250mm
› Diameter 250mm › Different sizes (XS, S, M, L, XL) to fit
the indoor unit
