INTRODUCTION

AIR PURIFIER

Office Unit control Integrating control Advanced control
HEATING

Tablet
BRC1H519W7/S7/K7 EKMBDXA DMS504B51 DMS502A51 DCC601A51 DCM601A51
1 gateway for max. 1 gateway for SPLIT
1 remote controller 64 indoor unit(s) 1 gateway for 128 indoor unit(s) 1 unit for 32 indoor 1 iTM for 64 indoor
for 1 indoor unit (groups) & 10 64 indoor unit(s) (groups), 20 out- unit(s) (groups) (5) unit(s) (groups) (1)
(group) (groups)
outdoors doors (2)
Automatic control of A/C      
Centralised control for management     
 SKY AIR
Local control for office staff   (4) through Web
Remote management
Limit control possibilities for office staff      
Integrate Daikin units into existing BMS via Modbus 
Integrate Daikin units into existing BMS via HTTP  VRV

Integrate Daikin units into existing BMS via LonTalk
Integrate Daikin units into existing BMS via BACnet 
Energy consumption read out  (3)
Monitor energy consumption  (4) 
Advanced energy management  (4)  VENTILATION & BID- DLE AIR CURTAINS
 
PPD software to distribute used kWh/indoor unit (6) (7)
Integrate Daikin cross pillar products 
into Daikin BMS
 
Integrate third party products into Daikin BMS
Online control  (4)  MARINE TYPES
Manage multiple sites  (4)  (5)
(1) 7 iTM plus adapters (DCM601A52) can be added to have 512 indoor groups and 80 outdoor (systems) (2) extension (DAM411B51) needed to have up to 256 indoor unit(s) (groups), 40 outdoors (3) Not
available on all indoor units (4) Via Daikin cloud service (5) Through own IT set-up (not Daikin cloud sever) (5) Up to 10 DCC601A51 can be combined as a single site on Daikin Cloud Service (6) via DAM412B51
option (7) via DCM002A51 option
CHILLERS

Infrastructure cooling Unit Integrating Advanced

FAN COIL UNITS

BRC1H519W7/S7/K7 RTD-10 DCM601A51
1 remote controller for 1 indoor 1 gateway for 1 indoor unit 1 iTM for 64 indoor unit(s)
unit (group) (2) (group) (groups) (1)
Up to 8 gateways can be linked AIR HANDLING UNITS
together
Automatic control of A/C   
Back-up operation   
Duty rotation   
Limit control possibilities in the technical cooling room    REFRIGERATION
If room temperature above max., then show alarm & start standby unit.  
If an error occurs, an alarm will be shown.   
If an error occurs, activate an alarm output Via KRP2/4A option (3)  Via WAGO I/O
(1) : 7 iTM plus adapters (DCM601A52) can be added to have 512 indoor groups and 80 outdoor (systems) (2) Infrastructure cooling functions only compatible with indoor units connected to RZQG*/RZAG*
outdoor units. (3) See option list of indoor unit CONTROL SYSTEMS
727
